| PERFORMANCE | |
| Max. prop shaft output | 18.4 kW / 25 HP |
| Full throttle operating range | 4500 ~ 5500 rpm |
| Idling speed | 750 ± 50 rpm |
| Fuel consumption | 13 L/h@5500 rpm |
| ENGINE | |
| Engine type | 2-Stroke, In-line 2 |
| Displacement | 496 cc |
| Bore × Stroke | 72.0 × 61.0 mm |
| Fuel induction system | 1 carburetor |
| Fuel tank | External, 24 L |
| Lubrication system | Pre-mixed fuel and oil (50 : 1) |
| Ignition system | CDI |
| Spark Plug | NGK B7HS-10 |
| Engine Start | Manual / Electric Start |
| Alternator | 6A, 80 W |
| Cooling system | Raw-water, thermostatically controlled |
| Propeller spec | 3-9 7/8'' x 11'' |
| BRACKET / DRIVE | |
| Steering | Tiller Handle |
| Steering Angle (maximum) | 45°from center, left and right |
| Trim Control System | Manual Tilt |
| Gear shift | F-N-R |
| Gear ratio | 2.08 (27/13) |
| Gear oil | 0.25 L |
| Engine transom height (Shaft length) | S: 440mm (17.3") / L: 570mm (22.4'') |
| Boat transom height | S: 380 mm / L: 510 mm |
| Net weight | S: 53 kg / L: 55 kg |
| PACKAGE | |
| Gross weight | S: 63 kg / L: 65 kg |
| Package size | S: 135.73.48 cm / L: 145.73.48 cm |
