| PERFORMANCE | |
| Max. prop shaft output | 7.2 kW / 9.8 HP |
| Full throttle operating range | 4000 ~ 4500 rpm |
| Idling speed | 900 ± 50 rpm |
| Fuel consumption | 5.1 L/h@4500 rpm |
| ENGINE | |
| Engine type | 2-Stroke, In-line 2 |
| Displacement | 169 cc |
| Bore × Stroke | 50.0 × 43.0 mm |
| Fuel induction system | 1 carburetor |
| Fuel tank | External, 12 L |
| Lubrication system | Pre-mixed fuel and oil (50 : 1) |
| Ignition system | CDI |
| Spark Plug | NGK B7HS-10 |
| Engine Start | Manual / Electric Start |
| Alternator | 7A, 80 W |
| Cooling system | Raw-water, thermostatically controlled |
| Propeller spec | 8.5 x 9 |
| BRACKET / DRIVE | |
| Steering | Tiller Handle |
| Steering Angle (maximum) | 45°from center, left and right |
| Trim Control System | Manual Tilt |
| Gear shift | F-N-R |
| Gear ratio | 2.08 (27/13) |
| Gear oil | 0.25 L |
| Engine transom height (Shaft length) | S: 440mm (17.3") / L: 570mm (22.4'') |
| Boat transom height | S: 380 mm / L: 510 mm |
| Net weight | S: 27.8 kg / L: 28.5 kg |
| PACKAGE | |
| Gross weight | S: 33 kg / L: 35 kg |
| Package size | S: 107*66*37.5 cm / L: 120*66*37.5 cm |
